ANT-DA1

Directional Antenna Suit, N type, To know more，click the 《Directional Antenna Datasheet》

Digital Modulation Analysis (SW)

100 kHz~3.6/ 7.5 GHz independent source, -40 dBm ~ 0 dBm (SW)

100 kHz-3.6/7.5 GHz vector network analyzer, vector S11 and S21 measurement (SW)

GPS Receiver (SW)

Analog Modulation Analysis (SW)

Open (F), short (F), Match/Load(F, 50 Ohms), Through (F-F ) DC – 9 GHz

Open (M), short (M), Match/Load(M, 50 Ohms), Through (M-M ) DC – 9 GHz

Performance verification script and guidance

NMD 3.5 female-NMD 3.5 Male DC-26.5 GHz,635 mm
