SP6150A 1.5 GHz Oscilloscope probe

Bandwidth: 1.5 GHz (X10) Input Resistance (Probe + Scope) 500Ω±10Ω Input Capacitance 1.8pF Scope Input Coupling 50Ω Operating Temperature: 0-50℃ For more information, view the SP6150A Datasheet

4 GHz power rail probe for use with all Siglent SAPBus enabled oscilloscopes. To learn more, click on the SAP4000P User Manual Bandwidth 4 GHz Low frequency resistance 20 kΩ High frequency resistance 50 Ω Offset voltage range ±24 V Attenuation ratio 1.1:1 Dynamic range ±600 mV

High-performance reference source

Material Measurement

Pulse measurement

Spectrum analysis

Scalar mixer measurement

SNA6000-TDR

Time-Domain analysis
